Tray vs floor fall layout
Can install directly onto tiled shower floor with threshold curb or stone shower tray.
Shower Screens
MPF-034 Diamond Shower Enclosure
A space-efficient diamond-shaped corner shower enclosure with a 135-degree pivot hinged door, crafted from 8mm certified tempered safety glass and solid 304 stainless steel hardware.
- Space-saving diamond corner layout freeing bathroom circulation pathways
- Precision solid 304 stainless steel hinges tested to 48-hr salt spray (Grade 10)
- 120° outward door opening angle with self-closing magnetic latch
- Customizable sizing and finishes (Mirror Chrome, Black, Gunmetal, Brushed Gold)
- Model
- MPF-034
- Dimensions
- Non-standard sizing available
- Configuration
- Diamond hinged door
- Finish / color
- Mirror / black / gunmetal / brushed gold
Model overview
MPF-034 Diamond-Shape Hinged Corner Shower Enclosure Specifications
A space-efficient diamond-shaped corner shower enclosure with a 135-degree pivot hinged door, crafted from 8mm certified tempered safety glass and solid 304 stainless steel hardware.
Optimal for medium-sized hotel bathrooms, corner ensuite layouts, and residential wet-and-dry separation. For wall-to-wall straight openings without corner angles, select MPF-030.
B2B Project Fit & Sourcing Guidance
Confirm MPF-034 for your market Optimal for medium-sized hotel bathrooms, corner ensuite layouts, and residential wet-and-dry separation.
Alternative selection: For wall-to-wall straight openings without corner angles, select MPF-030.
Technical specifications
Engineering Data & Sourcing Specifications for MPF-034
Drawing-level parameters, water conservation performance, and export logistics data for project evaluation.- Product model
- MPF-034
- Product type
- Diamond Shower Enclosure
- Dimensions
- Non-standard sizing available
- Installation / Outlet
- Diamond hinged door
- Finish / Color
- Mirror / black / gunmetal / brushed gold
- Product family
- Shower Screens
- Flushing Technology
- Full-perimeter magnetic seal with bottom water deflection bar
- Trapway & Waste Path
- Wall channel adjustment ±10 mm
- Water Seal Depth
- 18 kg steel ball impact certified tempered glass
- Container Loading (40HQ)
- ~200 sets / 40HQ container
- OEM / Customization Scope
- Custom glass heights, PVD hardware finishes, OEM packaging with project installation manuals
Shower enclosure measurement checklist
What buyers should confirm for MPF-034
Accurate finished dimensions are required to define the door, glass and hardware configuration.Wall structural anchoring
Hinged door weight requires solid masonry or reinforced timber studs behind wall profiles.
Door swing clearance
Verify that pivot door does not collide with vanity cabinet or toilet bowl when open.
Export wooden crate packaging
Dense glass crate packaging yields approx. 200 sets per 40HQ container.
Category engineering
Shower Screen Manufacturing Advantages
MICAWA shower screens combine certified tempered safety glass, corrosion-tested framing, durable sliding or hinged hardware and custom dimensional support.Automotive-grade tempered glass
Standard 8 mm float tempered glass can be upgraded to 10 mm and is covered by China Compulsory Certification (3C).
Safer breakage characteristics
A 50 × 50 mm area produces at least 60 fragments, while polished corners use a radius of at least 3 mm to reduce edge risk.
Optional safety film
A nano safety and anti-explosion film can be specified for added breakage retention.
Impact verification
Glass assemblies pass an 18 kg steel-ball drop impact test.
Corrosion-resistant frames
Options include 1.2–1.8 mm food-grade 304 stainless steel with Grade 10 rust resistance after 48-hour neutral salt spray, or ≥95% pure aluminium with 13–14 HW hardness and ≥10 μm anodised film.
Durable quiet sliding system
Stainless-steel bearing rollers complete at least 50,000 cycles without sticking or abnormal noise, operate at no more than 45 dB and include anti-derailment and damping features.
Solid stainless-steel hinges
Hinges reach Grade 10 rust resistance after 48-hour salt spray and support opening angles up to 120°.
Age-resistant water sealing
High-elasticity EVM magnetic seals withstand temperatures from -20°C to 70°C and use a double-layer U-shaped water barrier.
Custom enclosure formats
Multiple shapes, heights and widths can be adjusted for non-standard project conditions.
These figures describe MICAWA’s category-level manufacturing, material and test capabilities. Confirm their applicability, optional functions and destination-market documentation for model MPF-034 against the current technical sheet and quotation.
Packaging & delivery
Packing checks for MPF-034
Confirm the packing plan after the product configuration is approved so protection, accessories, marks and loading data match the order.
- Glass edge and corner protection
- Hardware set identification
- Crate and shipping-mark requirements
- Handling and installation sequence
Product presentation
Need a closer view before shortlisting?
Request the current product presentation package for model MPF-034, including available detail imagery and video material.Model inquiry
Request the current specification and quote for MPF-034
Share your finished opening dimensions, door format and direction, glass thickness, hardware finish, quantity and project location. MICAWA will review the request against the current MPF-034 technical information and available supply configuration.Continue exploring
Compare shower enclosures and coordinated shower products
Compare related MICAWA models and confirm the best fit for the same purchasing brief.
M-6145F Freestanding Bathtub Faucet
Confirm with current technical sheet Floor-mounted bathtub faucet
View productShower Screens FAQ
Questions to confirm for MPF-034
Use the current product sheet and approved quotation as the final reference for this model.Which finished-opening measurements are needed for MPF-034?
Provide wall-to-wall dimensions, height and out-of-square conditions after wall and floor finishes are complete.
Which glass and hardware options should be confirmed for MPF-034?
Confirm glass thickness, safety treatment, frame material, hardware finish and door direction against the current drawing.
How should water sealing be reviewed for MPF-034?
Share tray or floor conditions, threshold details and splash-control expectations so seals and configuration can be checked.
